- Over 100 hours' working time with 2x AA rechargeable batteries
- New features: Pairs with LS310 Series Light Source to auto-verify source wavelength and run dual-λ testing
- VFL function to identify fiber bends and faults
- Auto shutdown and self-calibration for convenience and accuracy
- USB interface and Toolbox software for easy data management
The AE2xx Series optical power meters are ideal for qualifying fiber optic-based physical layer applications, including FTTx, CATV, PON, and long-haul networks. Designed with user convenience in mind, these versatile instruments support up to 9 wavelengths — covering the full range required for these applications.
Built for field use, these handheld units offer exceptional accuracy, low power consumption, and portable durability. With multiple models available, finding the right configuration to match your testing needs is simple.
Specifications:
- Wavelengths: 850/980/1300/1490/1550/1610/1625/1650nm
- Power Measurement Range: -70 to +10dBm ±0.17dB
- Visual Fault Locator (VFL): 650nm, 10mW
- Connectors: FC/SC changeable, APC/UPC adapter selectable
Standard Accessories Include:
- Rechargeable 1.8Ah NiMH battery
- Carrying case
- Battery charger
- Three-year product warranty
- One-year battery & accessory warranty
